Vado Size Guide
Forward 50 LTD - Limited to 250 numbered bikes only at select retailers
E-Bike System - Specialized SL 1.2 / 320 watts / Up to 5 Hours Range
Weight - Ultralight Carbon E-Bike: 14.9kg / 33.0lbs
Suspension - Future Shock 3.2
Personalization and Security - Fitness Metrics, Apple Find My, Turbo System Lock, Lights
Frame
2024 Vado SL
Specialized integrated
Specialized integrated
Specialized Vado SL2 Carbon, Tubus front rack mounts up to 14kg
Specialized Vado SL2 Carbon, Tubus front rack mounts up to 14kg
Seat Post
Roval Carbon Fiber, 30.9 mm, Offset 21mm
Saddle
Specialized Power Pro Mirror, Forward 50 limited edition, Nylon recycle base, Hollow-ti pink rail,155mm
Stem
Specialized Stealth Stem, Alloy, 31.8mm, Integrated Display And Light Mount, Size S/M : 60mm 17 Deg, L/XL : 75mm 15.5 Deg
Grips
ERGON, GA30-S Custom, 134.8mm Length
Handlebars
Specialized Carbon Handlebar, 10 Rise, 8 B-SWP, 6 U-SWP, 720mm, 31.8mm
Front Brake
SRAM Level Silver Stealth
Rear Brake
SRAM Level Silver Stealth
Shift Levers
SRAM AXS POD Controller
Rear Derailleur
SRAM FORCE XPLR AXS D2 MAX 44T
Cassette
SRAM XG 1251 D1 XPLR 10-44
Shift Levers
SRAM AXS POD Controller
Crankset
SRAM FC S996 Carbon, S-165mm / M-L-170mm / XL-175mm
Chain
SRAM CN Force 12-speed
Chain Ring
SRAM 107BCD 44T Narrow Wide
Front Wheel
Roval Terra Carbon CL, 25mm internal width, 32mm depth, 24h, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes
Rear Wheel
Roval Terra CL, 25mm internal width, 32mm depth, 24holes, Tubeless ready, DT for Roval 350 hub, Centerlock disc, DT Swiss Competition Race spokes
Front Tire
Specialized Hemisphere flat protection, Reflective side walls, Wirebead, All terrain tire, 700x47c
Rear Tire
Specialized Hemisphere flat protection, Reflective side walls, Wirebead, All terrain tire, 700x47c
Tubes
Turbo Tube W/Talc 60mm 29X1.75-2.4
Motor
Specialized 1.2 SL System
Mastermind H3, W/Handlebar Remote, Ant+/Bluetooth®, Built-In System Lock Feature, Integrated Apple Find My, Coloured Customizable Display Pages, 2.1"
Mastermind H3, W/Handlebar Remote, Ant+/Bluetooth®, Built-In System Lock Feature, Integrated Apple Find My, Coloured Customizable Display Pages, 2.1"
Battery
Specialized SL2-520, Fully Integrated, 520Wh
Charger
Custom charger, 48V System w/ SL system charger plug
Wiring Harness
Custom Specialized wiring harness w/ chargeport
Pedals
Specialized Commuter w/ grip tape & reflectors
Headlight
Lezyne, Ebike Fusion Stvzo E500+, 500 Lumen, 50Cm Wire, With Reflector
Tail Light
Specialized integrated saddle mount, LED Technology, 12V
Bell
Specialized brass bell
