Specialized

Turbo Levo 4 Comp Alloy

Turbo Levo 4 Comp Alloy

95226-5001

$10,200.00
$10,200.00
Sale Contact Us for Availability
Tax included.
Colour
Size
View Size Guide
View full details

Product Details

The Specialized Science Club Introduces the Levo 4, an electric mountain bike so advanced it transforms you into a cycling cyborg. Together you're SuperNatural, fortified with super power, traction, control, and range to conquer any off-road terrain. Levo 4, Where Super Meets Natural. Use - Full Power E-MTB Trail

E-System - Specialized 3.1 Motor w/ 666 Watts & 101Nm, 840Wh Battery, up to 5.33 hour range

Frame - Premium M5 Alloy, Geo Adj & SWAT Storage

Suspension - Front: 160mm FOX 36 Rhythm GRIP, Rear: 150mm GENIE - FOX FLOAT X Performance

Drivetrain - SRAM 90 Eagle T-Type Mechanical

Wheels - Specialized Alloy / Bear Pawls hubs







Technical Specifications

Frameset

Frame

All new Levo 4 M5 Alloy frame, 150mm travel,, adjustable chainstay, adjustable head tube angle, adjustable bottom bracket, internal SWAT storage 148mm spacing, 29" front wheel/27.5" rear wheel, fork travel up to 180mm

Seat Binder

Alloy, 38.6mm

SWAT

SWAT internal downtube storage

Suspension

Rear Shock

FOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment, 210x55mm

Fork

FOX 36 Rhythm, 29", S2-S6: 160mm S1: 150mm, GRIP damper with Sweep adjust, 44mm offset, 15x110mm boost, through axle

Cockpit

Seat Post

X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 100mm, S2: 125mm, S3: 150mm, S4: 170mm, S5/S6: 190mm

Saddle

Bridge Comp, Hollow Cr-mo rails 155/143

Stem

Alloy Trail Stem, 35mm bar bore

Grips

Specialized Trail Grips

Handlebars

Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, S1-S2: 780mm width, S3-S6 800mm width

Brakes

Front Brake

SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm Centerline rotor

Rear Brake

SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm Centerline rotor

Drivetrain

Shift Levers

SRAM 90 trigger, 12-speed, single click

Rear Derailleur

SRAM Eagle 90 T-Type

Cassette

SRAM XS-1275, 12-speed, 10-52t

Shift Levers

SRAM 90 trigger, 12-speed, single click

Crankset

SRAM S1000 Crankset, ISIS Interface, Integrated Guard, 55mm Chainline, 155mm

Chain

SRAM GX Eagle T-Type Flattop Chain, 12-speed

Chain Ring

SRAM 34t T-Type chainring, 104 BCD, steel

Wheels & Tyres

Front Hub

Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h

Rear hub

Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h

Rims

Specialized, hookless alloy, 30mm inner width, tubeless ready

Butcher, GRID GRAVITY casing, GRIPTONĀ® T9 compound, TLR, 29x2.4"

Butcher, GRID GRAVITY casing, GRIPTONĀ® T9 compound, TLR, 29x2.4"

Butcher, GRID GRAVITY casing, GRIPTONĀ® T9 compound, TLR, 27.5x2.4"

Butcher, GRID GRAVITY casing, GRIPTONĀ® T9 compound, TLR, 27.5x2.4"

Spokes

DT Swiss Industry

Tubes

Standard, Presta valve

E-Bike

Motor

All New Specialized 3.1 Motor, 101Nm torque, 666Nm power

UI Remote

All New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized App

Battery

840Wh battery

Charger

Specialized 4amp charger
