We tossed gravel geometry status quo out the window. The new Diverge has the most progressive geometry we’ve ever created for a drop bar bike, giving riders a capable and stable bike in the dirt that still feels responsive and nimble on the road. We’ve increased the frame’s reach, introduced a slacker head tube and a longer offset fork. All this creates incredible confidence with a planted feeling in the dirt while spec’ing shorter stems keeps the overall cockpit length the same and the steering lively. We’ve kept the bike’s BB low to increase stability but high enough to utilize with 650b wheels if that’s your jam.
We’ve given the Diverge plenty of rack mounts, including fork and top tube mounts, to ensure you can take what you need, no matter how far you plan to go, or how long you plan to stay out.
Nothing unlocks a bike’s capability like tire clearance, so we gave the new Diverge a whopping 47mm of tire clearance with a 700c wheel and 2.1” with a 650b wheel.
Frame
Specialized Diverge E5 Premium Aluminum, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc
Seat Binder
Alloy, 30.8mm
Fork
FACT carbon, full carbon steerer, 12x100 mm thru-axle, flat-mount disc
Seat Post
Alloy, 2-bolt Clamp, 12mm offset, 27.2mm, anti-corrosion hardware
Saddle
Body Geometry Bridge Saddle, steel rails
Stem
3D-forged alloy, 31.8mm, 7-degree rise
Bar Tape
Supacaz Suave
Handlebars
Specialized Shallow Drop, 6061, 70x125mm, 31.8mm clamp
Front Brake
Shimano CUES Hydraulic Brake
Rear Brake
Shimano CUES Hydraulic Brake
Shift Levers
Shimano CUES ST-U6030
Front Derailleur
Shimano CUES FD-U6030, Braze-on
Rear Derailleur
Shimano CUES RD-U6020, 10sp
Cassette
Shimano CUES, 11-39T, 10sp
Shift Levers
Shimano CUES ST-U6030
Crankset
Shimano CUES FC-U6030, 46/32T
Chain
KMC XGlide
Bottom Bracket
Shimano Threaded BSA BB
Front Wheel
AXIS Sport Disc
Rear Wheel
AXIS Sport Disc
Front Tire
Pathfinder Wirebead Fast Gravel 700X40C
Rear Tire
Pathfinder Wirebead Fast Gravel 700X40C
Tubes
700x28/38mm, 48mm Presta valve
