Specialized

Chisel Comp EVO

Chisel Comp EVO

SKU:93825-5602

Regular price $5,800.00
Regular price $0.00 Sale price $5,800.00
Sale Contact Us for Availability
Tax included.
Colour
Size
View Size Guide
View full details

Product Details

The Lightest, Fastest Alloy Full Suspension Bike in the World gets a full makeover with the ultra-capable EVO build. Still 18.4% lighter than the closest competitor and sharing geometry and kinematics from our downcountry-hungry Epic 8 EVO, the all-new Chisel Comp EVO delivers the performance you can feel and is spec’d for the ultimate downcountry experience. SPEED METAL: With D’Aluisio Smartweld technology, the Chisel Comp EVO boasts the lightest aluminum XC frameset in its class. Each highly manipulated frame tube features continuously varied wall thicknesses and shaping that deliver stiffness where you need it– for efficiency – and ride-smoothing compliance where you want it—for comfort and optimal control. UNMATCHED CAPABILITY: With a slew of trail-ready specs, including a bump up to 130mm of travel up front, the Chisel EVO eats up the chunk and feels right at home on the rough stuff. Advanced suspension kinematics, Ride Dynamics tuned suspension, and progressive geometry, can all be found in the Chisel Comp EVO, making it more than capable of handling big rides with confidence and speed. INCREDIBLE EFFICIENCY: The Chisel Comp EVO is the most efficient pedaling bike in its class, thanks to the utilization of geometry and kinematics that went into our Epic 8 EVO platform. The steep seat tube positions you in the optimal pedaling position to save energy for the long rips down. Honed anti-squat reduces pedal-bob. Put it together, and Chisel Comp EVO translates every watt applied to the pedals into maximum forward motion. SMOOTHER IS FASTER: We engineered a flex stay rear end for class-leading suspension performance while eliminating the extra weight and maintenance associated with pivots required in a traditional design. More common on carbon bikes, extensive field and lab testing proves that Chisel Comp EVO has achieved the impossible—the efficiency, control, and lightweight of a flex stay design in the advanced alloy. HYDROFORMED ALLOY: Chisel Comp EVO shaves extra material and weight with a one-piece hydroformed seat tube that integrates the seat tube pivot, main pivot, and BB shell. On a more traditional bike, the seat tube is typically just a "tube" with pivots and BB shell welded on. D’Aluisio Smartweld hydroformed tubes and engineered tube junctions, flip chip geo adjust, 110mm travel

FOX 34 Performance Elite 130mm with Grip 2 damper

Ride Dynamics Tuned FOX FLOAT Performance rear shock

TranzX dropper post (100mm-170mm)

SRAM GX Eagle Rear derailleur

SRAM G2 RS 4-piston brakes

Specialized Purgatory Grid T9 tire (front)

Specialized Ground Control Grid T7 tire (rear)

20mm Rise Handlebars

Technical Specifications

Frameset

Frame

Specialized D'Aluisio Smartweld M5 Alloy, Hydroformed tubes, Progressive XC Geometry, 110mm travel, internal cable routing, BSA BB, 12x148mm spacing, 30.9mm Dropper post compatible

Seat Binder

Specialized Alloy, 34.9mm

Suspension

Rear Shock

Fox Float Performance, Evol LV, Ride Dynamics Tuned, 2-position compression adjust, 190x40mm

Fork

Fox 34 Performance Elite, Grip2 Damper, Compression adjust, 130mm travel, 44mm offset, 15x110mm

Cockpit

Seat Post

X-Fusion Manic, 30.9, 125/150/170 Travel, 0mm offset

Saddle

Body Geometry Power Comp, steel rails

Stem

Alloy Stem, 35mm clamp, 60mm

Grips

Specialized Trail Grips

Handlebars

Specialized Alloy, 20mm rise, 35mm, 760mm wide

Brakes

Front Brake

SRAM G2 RS hydraulic disc, 4-Piston Caliper, 180mm rotor

Rear Brake

SRAM G2 RS hydraulic disc, 4-Piston Caliper, 180mm rotor

Drivetrain

Shift Levers

SRAM GX, trigger, 12-speed

Rear Derailleur

SRAM GX Eagle, 12-speed

Cassette

SRAM PG-1230 Eagle 11-50t

Shift Levers

SRAM GX, trigger, 12-speed

Crankset

SRAM X1000 Eagle, DUB, 165/170/175mm

Chain

SRAM SX Eagle, 12-speed

Bottom Bracket

SRAM DUB, BSA 73mm, Threaded

Chain Ring

32t

Wheels & Tyres

Front Hub

Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h

Rear hub

Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h

Rims

Specialized 29, hookless alloy, 30mm inner width, tubeless ready

Front Tire

Specialized Purgatory, GRID Casing, T9 Compound, 29x2.4

Rear Tire

Specialized Ground Control, GRID Casing, T7 Compound, 29x2.35

Spokes

DT Swiss Industry

Tubes

Standard 40mm PV 29x1.75-2.4
